9–4 Maintenance and Service Guide
Connector pin assignments
RJ-45 (network)
Universal Serial Bus
Pin Signal
1Transmit +
2Transmit -
3 Receive +
4 Unused
5 Unused
6 Receive -
7 Unused
8 Unused
Pin Signal
1+5 VDC
2Data
3Data +
4 Ground
