4–16 Maintenance and Service Guide
Removal and replacement procedures
Keyboard
✎
The keyboard spare part kit includes a keyboard cable.
Before removing the keyboard, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on,
and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet, and then
unplugging the AC adapter from the computer.
4. Remove the battery (see “Battery” on page 4-6).
Remove the keyboard:
1. Position the computer with the front toward you.
2. Remove the following screws:
❏ The Phillips PM2.0x6.0 screw 1 that is near the hard drive bay
❏ The Phillips PM2.0x4.0 screw 2 in the battery bay
Country or region Spare part number Country or region Spare part number
■ Belgium 580687-A41 ■ Russia 580687-251
■ Brazil 580687-201 ■ Saudi Arabia 580687-171
■ The Czech Republic 580687-221 ■ South Korea 580687-AD1
■ France 580687-051 ■ Spain 580687-071
■ French Canada 580687-121 ■ Switzerland 580687-BG1
■ Germany 580687-041 ■ Taiwan 580687-AB1
■ Italy 580687-061 ■ Thailand 580687-281
■ Japan 580687-291 ■ Turkey 580687-141
■ Latin America 580687-161 ■ The United Kingdom 580687-031
■ The Netherlands 580687-B31 ■ The United States 580687-001
■ Portugal 580687-131
