Removal and replacement procedures
Maintenance and Service Guide 4–17
3. Turn the computer right-side, up and open the display to a 90-degree angle.
4. Then position the computer so that the display is its base and the keyboard is in the upright position.
5. On the bottom of the computer, press in on the keyboard release tabs.
6. Return the computer to its upright position.
7. Lift the rear edge of the keyboard until it rests at an angle.
8. Slide the keyboard back until it rests on the switch cover and display.
