Illustrated parts catalog
Maintenance and Service Guide 3–3
Item Description Spare part number
1 13.3-in, LED, HD display assembly (includes 2 WLAN antenna transceivers and cables, nameplate, and logo):
13.3-in, LED, HD BrightView (1366x768) (Intel systems) 580664-001
13.3-in, LED, HD BrightView (1366x768) MA (AMD systems) 581177-001
13.3-in, HD BrightView (1366x768) WWAN (AMD systems) 591222-001
Display assembly internal components (not illustrated):
Display bezel 580666-001
Display hinges 580667-001
13.3in Display panel 588159-001
13.3in Display panel, WWAN 591223-001
2 Keyboard (includes keyboard cable):
For use in the United States 575926-001
For use in the United Kingdom 575926-031
For use in Germany 575926-041
For use in France 575926-051
For use in Italy 575926-061
For use in Spain 575926-071
French Canada 575926-121
For use in Portugal 575926-131
For use in Turkey 575926-141
For use in Latin American 575926-161
For use in Saudi Arabia 575926-171
For use in Brazil 575926-201
For use in the Czech Republic 575926-221
For use in Russia 575926-251
For use in Thailand 575926-281
For use in Japan 575926-291
For use in Belgium 575926-A41
For use in Taiwan 575926-AB1
For use in South Korea 575926-AD1
For use in the Netherlands 575926-B31
For use in Switzerland 575926-BG1
For use in Denmark, Norway, Sweden 575926-DH1
3 Top cover
AMD systems 583925-001
Intel systems 580692-001
4 Bluetooth module 537921-001
5 Front LED board 580843-001
6 Fan 580696-001
