HP PAVILION DV2700 User Manual

2.
Remove the Phillips PM2.5×9.0 screw that secures the display assembly to the computer.
3.
Turn the computer display-side up, with the front toward you.
4.
Open the display as far as possible.
5.
Disconnect the following cables:
(1) Display panel cable
(2) Camera module cable
(3) Microphone cable
6.
Remove the camera module, microphone, and wireless antenna cables from the hole in the system
board and the routing channels (4) built into the top cover.
CAUTION: The display assembly will be unsupported when the following screws are removed. To
prevent damage to the display assembly, support it before removing the screws.
7. Remove the two black Phillips PM2.5×5.0 screws (1) and the two Phillips PM2.5×7.0 screws (2)
that secure the display assembly to the computer.
Component replacement procedures 83

HP PAVILION DV2700 Specifications

General

Processor	Intel Core 2 Duo
RAM	Up to 4 GB DDR2
Display	14.1-inch
Screen Resolution	1280 x 800
Storage	120GB to 250GB HDD
Graphics	NVIDIA GeForce 8400M GS
Operating System	Windows Vista
Optical Drive	DVD±RW DL LightScribe
Wireless	802.11a/b/g
Ports	3 USB 2.0, VGA, HDMI, Ethernet, headphone/microphone jacks, ExpressCard/54 slot
Weight	5.4 lbs
Battery Life	Varies by usage
