Phillips PM2.5×6.0 captive screw
Color Quantity Length Thread Head diameter
Black 5 6.0 mm 2.5 mm 5.0 mm
Where used:
(1) One captive screw (secured by a C-clip) that secures the WLAN compartment cover to the computer
(2) Two captive screws (secured by C-clips) that secure the memory module compartment cover to the
computer
(3) Two captive screws (secured by C-clips) that secure the hard drive bay cover to the computer
Phillips PM2.5×6.0 captive screw 101
