Optical drive
NOTE: All optical drive spare part kits include an optical drive bezel.
Description Spare part number
For use in dv3000 models:
DVD±RW and CD-RW Super Multi Double-Layer Combo Drive 468813-001
DVD/CD-RW Combo Drive 468812-001
For use in dv3500 models:
DVD±RW and CD-RW Super Multi Double-Layer Combo Drive 496116-001
DVD±RW and CD-RW Super Multi Double-Layer Combo Drive with LightScribe 496117-001
Before removing the optical drive, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 43).
Remove the optical drive:
1. Slide the optical drive release latch (1) to release the optical drive from the computer.
2. Remove the optical drive (2) by sliding it out of the optical drive bay.
To insert the optical drive, insert the rear edge of the optical drive into the optical drive bay and slide it
in until the optical drive is seated. The optical drive release latch automatically locks the optical drive
into place.
48 Chapter 4 Removal and replacement procedures
