Page #101 background imageLoading...
Page #101 background image
Removal and replacement procedures
Maintenance and Service Guide 4–59
Processor
The processor spare part kit includes replacement thermal material.
Before removing the processor:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on,
and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first disconnecting the power cord from the AC outlet and then
disconnecting the AC adapter from the computer.
4. Remove the battery (see “Battery” on page 4-7).
5. Remove the following components:
a. Hard Drive (see “Hard Drive” on page 4-8)
b. Memory module (see “Memory module” on page 4-10)
c. RTC battery (see “RTC battery” on page 4-12)
d. WLAN module (see “WLAN module” on page 4-15)
e. Optical drive (see “Optical drive” on page 4-19)
f. Keyboard (see “Keyboard” on page 4-20)
g. Keyboard cover (see “Keyboard cover” on page 4-23)
h. Speaker assembly (see “Speaker assembly” on page 4-26)
i. Display assembly (see “Display assembly” on page 4-27)
j. Top cover (see “Top cover” on page 4-34)
k. System board (see “System board” on page 4-50)
l. Heat sink assembly (see “Heat sink assembly” on page 4-55)
Description Spare part number
Intel Arrandale CPU-uPGA Single-Core i5-520M (2.4 GHz, 3-MB L3 cache, 1066 MHZ SC Turbo) 594187-001
Intel Arrandale CPU-uPGA Single-Core i5-540M (2.53 GHz, 3-MB L3 cache, 1066 MHZ SC Turbo) 594188-001
