6–2 Maintenance and Service Guide
Specifications
14.1-in WXGA BrightView display specifications
Metric U.S.
Dimensions
Height 30.37 cm 11.96 in
Width 18.98 cm 7.47 in
Diagonal 35.82 cm 14.10 in
Number of colors More than 262,144
Contrast ratio More than 300:1
Brightness 200 nits (typical)
Pixel resolution
Pitch 0.2373 × 0.2373 mm
Format 1280 × 800
Configuration RGB vertical stripe
Backlight CCFT
Character display 80 × 25
Total power consumption 5.2 W
Viewing angle ±40° horizontal, +15°/-35° vertical (typical)
