4–24 Maintenance and Service Guide
Removal and replacement procedures
2. Turn the computer display-side up with the front toward you.
3. Open the computer as far as possible.
4. Remove the Phillips PM2.5×8.0 screw 1 and the Phillips PM2.5×4.0 screw 2 securing the keyboard cover to
the top cover.
5. Disconnect the LED board cable 3.
6. Release the keyboard cover 4 by sliding it toward the display assembly until it disengages from the computer.
7. Remove the keyboard cover.
Reverse this procedure to install the keyboard cover.
