Phillips PM2.5×6.0 captive screw

Color Quantity Length Thread Head diameter

Black 4 6.0 mm 2.5 mm 5.0 mm

Where used:

(1) One captive screw that secures the Mini Card module compartment cover to the computer (screw

is secured by a C-clip)

(2) One captive screw that secures the memory module compartment cover to the computer (screw is

secured by a C-clip)

(3) Two captive screws that secure the hard drive bay compartment cover to the computer (screws are

secured by C-clips)

Phillips PM2.5×6.0 captive screw 131

Questions and Answers:

Need help?

Do you have a question about the HP PAVILION DV5 and is the answer not in the manual?

General

CPU	Intel Core 2 Duo
Graphics	NVIDIA GeForce 9600M GT
Memory	4GB DDR2
Display	15.4"
Screen Resolution	1280x800
Hard Drive	250 GB HDD
Operating System	Windows Vista
Optical Drive	DVD±RW
Wireless	802.11a/b/g/n
Weight	2.65 kg
Ports	3 x USB 2.0, 1 x HDMI, 1 x VGA, 1 x RJ-45, 1 x ExpressCard/54
