Perform the following steps to disassemble the display assembly:

1. Remove all screw covers (1) and screws (2) that secure the display bezel to the display assembly.

2. Lift up and out on the left and right inside edges (1) and the top and bottom inside edges (2) of the

display bezel until the bezel disengages from the display assembly.

3. Remove the display bezel (3).

Display 155

Questions and Answers:

Need help?

Do you have a question about the HP PAVILION DV5 and is the answer not in the manual?

General

CPU	Intel Core 2 Duo
Graphics	NVIDIA GeForce 9600M GT
Memory	4GB DDR2
Display	15.4"
Screen Resolution	1280x800
Hard Drive	250 GB HDD
Operating System	Windows Vista
Optical Drive	DVD±RW
Wireless	802.11a/b/g/n
Weight	2.65 kg
Ports	3 x USB 2.0, 1 x HDMI, 1 x VGA, 1 x RJ-45, 1 x ExpressCard/54
