Item Description Spare part number
(7) Bluetooth module cable 489822-001
Cable Kit, includes:
NOTE: See
Cable Kit on page 31 for more Cable Kit spare part information.
501891-001
(8a) Power connector cable
(8b) Modem module cable
(8c) TV tuner module antenna cable
Plastics Kit, includes:
NOTE: See
Plastics Kit on page 30 for more Cable Kit spare part information.
486793-001
(9a) ExpressCard slot bezel
(9b) Mini Card module compartment cover
(9c) Memory module compartment cover
(9d) Hard drive bay cover
(10) Top covers (include TouchPad and TouchPad buttons):
For use only with computer models equipped with a fingerprint reader 486527-001
For use only with computer models not equipped with a fingerprint reader 486526-001
(11) Modem modules:
NOTE: The modem module spare part kits do not include a modem module cable. The modem module cable is
included in the Cable Kit, spare part number 501891-001.
For use in all countries and regions except Australia and New Zealand 461749-001
For use only in Australia and New Zealand 461749-011
(12) System boards (include replacement thermal material):
For use only with computer models equipped with AMD processors:
●
With RX781 Northbridge and ATI-M82-S discrete graphics subsystem memory
482324-001
●
With RS780 Northbridge and ATI-M UMA graphics subsystem memory
482325-001
For use only with computer models equipped with Intel processors:
●
With PM45 Northbridge and nVidia NB9P-GS discrete graphics subsystem
memory and 512-GB of graphics subsystem memory
482870-001
●
With PM45 Northbridge and nVidia NB9M-GE discrete graphics subsystem
memory and 256-GB of graphics subsystem memory
482867-001
●
With GM45 Northbridge and UMA graphics subsystem memory
482869-001
●
With ICH9M Northbridge and UMA graphics subsystem memory
482868-001
(13) Audio/infrared board (includes cable) 486797-001
(14) USB board (includes cable) 486798-001
(15) Processors (include replacement thermal material):
AMD processors:
20 Chapter 3 Illustrated parts catalog
