2. Remove the WLAN antenna cables from the clips (3) built into the top cover.

CAUTION: Support the display assembly when removing the following screws. Failure to support

the display assembly can result in damage to the display assembly and other computer

components.

3. Remove the four Phillips PM2.5×7.0 screws (1) that secure the display assembly to the computer.

4. Remove the display assembly (2).

NOTE: Steps 5 through 22 provide display assembly internal component removal information for

computer models equipped with AntiGlare display assemblies. See steps 23 through 32 for display

assembly internal component removal information for computer models equipped with BrightView

display assemblies.

NOTE: See Webcam/microphone module on page 53 for webcam/microphone module

replacement instructions for computer models equipped with BrightView display assemblies.

Component replacement procedures 77
