5–34 Maintenance and Service Guide
Removal and Replacement Procedures
2. Close the computer.
3. Turn the computer upside down with the rear panel
toward you.
4. Make note of which wireless antenna cable is attached to
which antenna clip on the Mini Card module before
disconnecting the cables. Then disconnect the cables 1 from
the module.
5. Remove the two Phillips PM2.5×7.0 screws 2 that secure the
display assembly to the computer.
Removing the Display Assembly Screws
