Table 3-1 Computer component descriptions and spare part information (continued)
Item Component Spare part number
Equipped with an Intel Core i5-9300H 2.4-GHz (turbo up to 4.1-GHz) processor (2666-MHz
FSB, 8-MB L3 cache, six cores, 45 W), an NVIDIA GeForce GTX 1050 graphics controller with
4-GB of discrete memory, and a non-Windows 10 operating system
L58863-001
Equipped with an Intel Core i5-9300H 2.4-GHz (turbo up to 4.1-GHz) processor (2666-MHz
FSB, 8-MB L3 cache, six cores, 45 W), an NVIDIA GeForce GTX 1050 graphics controller with
3-GB of discrete memory, and the Windows 10 operating system
L58862-601
Equipped with an Intel Core i5-9300H 2.4-GHz (turbo up to 4.1-GHz) processor (2666-MHz
FSB, 8-MB L3 cache, six cores, 45 W), an NVIDIA GeForce GTX 1050 graphics controller with
3-GB of discrete memory, and a non-Windows 10 operating system
L58862-001
Thermal Grease Replacement Kits (not illustrated):
Includes Liquid Metal thermal grease and normal thermal grease L65923-001
Includes only normal thermal grease L65268-001
Thermal Pad Replacement Kit (not illustrated) L56901-001
(9) Memory modules (2, DDR4, 2666 MHz, 1.2 V):
16 GB 937438-855
8 GB 937236-855
4 GB L10598-855
(10) Power connector cable (includes AC adapter and battery light) L56904-001
(11) I/O bracket (not available as a spare part)
(12a) USB/audio board (includes 2 USB ports and 1 audio combo jack; does not include cable) L56902-001
(12b) USB/audio board cable L56903-001
(13) WLAN module:
Intel 9560 ac 2×2 MU-MIMO + Bluetooth 5.0 M.2 non-vPro MIPI+BRI WW with two antenna L22634-005
Realtek RTL8822BE ac 2×2 MU-MIMO + Bluetooth 4.2 M.2 PCI-e WW with two antenna 924813-855
(14) Speakers (includes left and right speakers, cables, and rubber isolator) L56909-001
(15a) Solid-state drive:
512-GB, 2280, PCIe-3×2×2, NVMe, solid-state drive + 32-GB 3D XPoint L56896-001
512-GB, PCIe-3×4 solid-state drive L57003-001
512-GB, 2280, PCIe, NVMe, solid-state drive L56895-001
256-GB, M.2 2280, PCIe-3×4, NVMe, solid-state drive with TLC L56894-001
256-GB, PCIe-3×2 solid-state drive L57002-001
128-GB, M.2 2280, PCIe-3×2 solid-state drive L56893-001
16-GB, M.2 2280, PCIe-3×2 solid-state drive L56897-001
(15b) Solid-state drive shield L56903-001
(16a) Hard drive (does not include hard drive bracket or hard drive cable):
2-TB, 5400-rpm, 7.2-mm 912487-855
20 Chapter 3 Illustrated parts catalog
