e.
Disconnect the display panel cable (3) from the display panel.
f. Remove the display panel. The display panel is available using spare part number
686921-001.
13. If it is necessary to replace the webcam/microphone module:
a. Disconnect the webcam/microphone module cable (1) from the webcam/
microphone module.
CAUTION: Handle the webcam/microphone module with caution. The module has a thin
profile and is susceptible to damage when not handled carefully.
Component replacement procedures
97
