HP Pavilion M703 User Manual

HP Pavilion MX703/M703 Monitor Guide
11
Item Subwoofer Purpose
M On button Turns on subwoofer
N Volume knob Adjusts subwoofer sound
level
O Subwoofer
audio cable
(green)
Carries audio signal,
plugs into PC
P Control cable
(purple)
Carries subwoofer control
signal to right speaker,
mutes speakers and
subwoofer when
headphones are
connected
Q Subwoofer
audio connector
(green)
Accepts right speaker
audio cable (green)
R Power adapter
cable connector
Accepts adapter cable
and carries power for
subwoofer
S Power adapter Provides power to
subwoofer (alternate two-
piece adapter not shown)
To place the two-speaker
and subwoofer system
1 Place the two speakers using the steps in
“To place the two-speaker system” on page 7.
2 Place the subwoofer on the top of, or under
your computer desk.
To connect the two-speaker
and subwoofer system
1 Plug the power adapter S cable into the back
of the subwoofer R. Plug the power adapter
into a wall receptacle.
2 Plug the right speaker audio cable (green) D
into the subwoofer connector (green) Q.
3 Plug the subwoofer control cable (purple) P
into the right speaker connector (purple) C.
4 Plug the subwoofer audio cable (green) R into
the PC. Refer to your PC user’s guide for
instructions on how to connect your speakers
to the PC.

HP Pavilion M703 Specifications

General

Brand	HP
Model	Pavilion M703
Category	Monitor
Language	English
