Item Component Spare part number
(1) Display assembly: The display assembly is spared at the subcomponent level only. For more display assembly spare part
information, see Display components on page 16.
(2) Keyboard/top cover (includes keyboard cable):
In cardinal red nish 856188-161
In modern gold nish 856187-161
In natural silver nish 856186-161
(3) Power connector cable 808155-010
(4) Battery (3-cell, 41-Wh, 3.61-Ah, Li-ion battery; includes cable) 849908-850
(5) Hard drive:
NOTE: The hard drive spare part kit does not include the hard drive brackets or the hard drive cable. The hard drive
brackets are not spared. The hard drive cable is available using spare part number 856205-001.
2-TB, 5400-rpm, SATA, 9.5-mm hard drive 801808-005
1-TB, 5400-rpm, SATA, 9.5-mm hard drive 778192-005
500-GB, 5400-rpm, SATA, 7.0-mm hard drive 778186-005
(6) Hard drive cable (includes double-sided adhesive) 856205-001
(7) Card reader board 863315-001
(8) Card reader board cable (includes double-sided adhesive) 856204-001
(9) Fan (includes cable) 856206-001
(10) Heat sink (includes replacement thermal material) 860260-001
(11) Realtek RTL8723BE 802.11b/g/n 1×1 WiFi + Bluetooth 4.0 Combo Adapter 855106-855
(12) TouchPad cable (includes double-sided adhesive) 856203-001
(13) System board (includes processor and replacement thermal material):
Equipped with an AMD A10-8700P 1.80-GHz (turbo up to 3.20-GHz) processor (1600-MHz
FSB, 2.0-MB L2 cache, quad core, 15-W), an AMD Radeon R6 Graphics subsystem with UMA
video memory, and the Windows 10 Professional operating system
860261-601
Equipped with an AMD A10-8700P 1.80-GHz (turbo up to 3.20-GHz) processor (1600-MHz
FSB, 2.0-MB L2 cache, quad core, 15-W), an AMD Radeon R6 Graphics subsystem with UMA
video memory, and a non-Windows operating system
860261-001
Equipped with an AMD A8-7410 2.20-GHz (turbo up to 2.50-GHz) processor (1600-MHz FSB,
2.0-MB L2 cache, quad core, 15-W), an AMD Radeon R5 Graphics subsystem with UMA
memory, and the Windows 10 Professional operating system
860262-001
Equipped with an AMD A8-7410 2.20-GHz (turbo up to 2.50-GHz) processor (1600-MHz FSB,
2.0-MB L2 cache, quad core, 15-W), an AMD Radeon R5 Graphics subsystem with UMA
memory, and a non-Windows operating system
860262-001
(14) Memory modules (PC3L, 12800, 1600):
8-GB 693374-005
4-GB 691740-005
2-GB 691739-005
(15) Speakers (includes cable) 856220-001
14 Chapter 3 Illustrated parts catalog
