537496-001 — Removing and Replacing the Hard Disk Drive 11
7 Replace the screw at the top of the drive cage.
8 Replace the three screws on the front of the computer
that secure the drive cage in the computer.
9 Replace the system fan by inserting the two lower
hooks on the fan (1) into the slots in the computer,
and then swinging the top of the fan (2) onto the
computer.
10 Press the fan until the metal tab locks it in place.
NOTE: This is one of the short screws on select
models.
NOTE: These are long screws.
1
2
