Pen holder
Description Spare part number
Pen holder 441146-001
Pen eject assembly 441145-001
Before removing the pen holder, follow these steps:
1.
Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2.
Disconnect all external devices connected to the computer.
3.
Disconnect the power cord.
4.
Remove the battery (see
Battery on page 36).
5.
Remove the following components:
a.
Pen (see
Pen on page 37)
b.
Hard drive (see
Hard drive on page 38)
c.
Memory module compartment cover (see
Memory module on page 43)
d.
Optical drive (see
Optical drive on page 42)
e.
Keyboard (see
Keyboard on page 47)
f.
Switch cover (see
Switch cover on page 50)
g.
Display assembly (see
Display assembly on page 52)
h.
Top cover (see
Top cover on page 59)
i.
Power switch assembly (see
Power switch assembly on page 63)
j.
System board (see
System board on page 66).
Remove the pen holder:
1. Remove the Phillips PM2.0×5.0 screw (1) that secures the pen eject assembly to the base enclosure.
2. Remove the pen eject assembly (2).
3. Remove the two Phillips PM2.0×5.0 screws (3) that secure the pen holder to the base enclosure.
68 Chapter 5 Removal and replacement procedures ENWW
