Phillips PM2.0×4.0 screw
Color Quantity Length Thread Head width
Black 23 4.0 mm 2.0 mm 5.0 mm
Where used:
(1) Two screws that secure the WWAN module to the computer (see
WWAN module on page 40)
(2) Two screws that secure the WLAN module to the computer (see
WLAN module on page 44)
Where used: One screw that secures the fingerprint reader board to the display bezel (see Display
assembly on page 52)
ENWW Phillips PM2.0×4.0 screw 93
