HP PCL 5 Quick Reference Guide

2 EN
2
Factory Default Print Environment Feature Settings (PCL)
(continued)
PRINT MODEL
• SOURCE TRANSPARENCY MODE = 0 (Transparent)
• PATTERN TRANSPARENCY MODE = 0 (Transparent)
• CURRENT PATTERN = Solid (Black)
• PATTERN REFERENCE POINT = 0,0
• PATTERN ROTATION = 0
RECTANGULAR AREA FILL
• HORIZONTAL RECTANGLE SIZE = 0
• VERTICAL RECTANGLE SIZE = 0
• PATTERN (AREA FILL) ID = 0
RASTER GRAPHICS
• RESOLUTION = 75 dpi
• PRESENTATION = 3
• COMPRESSION MODE = 0
• LEFT GRAPHICS MARGIN = 0
• RASTER WIDTH = Logical Page
• RASTER HEIGHT = N/A
TROUBLESHOOTING COMMANDS
• END-OF-LINE WRAP = OFF
• DISPLAY FUNCTIONS = OFF
STATUS READBACK
• CURRENT LOCATION TYPE = 0
• CURRENT LOCATION UNIT = 0
Factory Default Print Environment Feature Settings
(HP-GL/2)
LINE AND FILL GROUP
• LINE TYPE = Solid
• LINE TYPE REPEAT LENGTH = 4% of the diagonal distance from P1
to P2.
• LINE CAP = Butt
• LINE JOIN = Mitered
• MITER LIMIT = 5
• PEN WIDTH = 0.35mm
• PEN WIDTH SELECTION MODE = Metric
• SELECTED PEN = No pen
• FILL TYPE = Solid (bi-directional)
• USER-DEFINED LINE TYPE = Eight standard line types
• ANCHOR CORNER = (0,0) plotter units
• USER-DEFINED FILL TYPES = Solid fill
• TRANSPARENCY MODE = On (transparency)
• SCREENED VECTOR = No screening
Learn.fm Page 2 Tuesday, June 22, 1999 8:17 AM
