Access Panel
Description Spare part number
Access panel 674373-001
1. Prepare the computer for disassembly (Preparation for Disassembly on page 43).
2. Loosen the captive Torx screw (1) on the back panel that secures the panel to the computer.
3. Slide the side panel toward the back (2), and then pull it away from the computer.
NOTE: Lay the computer on its side to install internal parts.
Figure 7-1 Removing the access panel
To replace the access panel, reverse the removal steps.
44 Chapter 7 Removal and Replacement Procedures – Microtower Chassis
