Access Panel
Description Spare part number
Access panel 656832-001
1. Prepare the computer for disassembly (Preparation for Disassembly on page 80).
2. If the computer is on a stand, remove the computer from the stand.
3. Remove the Torx screw that secures the access panel to the computer.
Figure 8-1 Removing the access panel screw
Access Panel 81
