3. Remove the memory module (2) by pulling the module away from the slot at an angle.
NOTE: Memory modules are designed with a notch to prevent incorrect insertion into the memory
module slot.
NOTE: The computer uses two memory sockets. The top socket houses the expansion memory
module and the bottom socket houses the primary memory module. The removal procedure is the same
for both memory sockets.
Reverse this procedure to install a memory module.
44 Chapter 5 Removal and replacement procedures for Customer Self-Repair parts
