Display assembly
All display assemblies include WLAN antenna transceivers and cables.
For a list of individual display spare parts, see
Display components on page 22.
Description Spare part number
Intel models:
Display assembly, 35.6-cm (14.0-inch), HD, anti-glare for use in models without a webcam and without
WWAN
721515-001
Display assembly for use in models with a webcam and with WWAN 721516-001
Display assembly for use in models with a webcam and without WWAN 724939-001
AMD models:
Display assembly for use in models with a webcam 722827-001
Before removing the display assembly, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet, and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 36).
5. Remove the following components:
a. Service door (see
Service door on page 37).
b. WLAN/Bluetooth module (see
WLAN/Bluetooth combo card on page 45)
c. WWAN module (see
WWAN module on page 47)
d. Keyboard (see
Keyboard on page 49)
e. Top cover (see
Top cover on page 53)
Remove the display assembly:
1. Position the computer upside down.
2. Remove the WLAN antennas from the tabs and the routing path on the bottom of the computer (1).
78 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
