Item Description Spare part number
(1) Display panel assembly, touch screen
NOTE: Touch displays are spared only as whole assemblies.
NOTE: Non-touch displays are spared only at the subcomponent level. Non-touch assemblies are
not spared as whole units.
L01102-001
(2) Keyboard (includes cable)
NOTE: For a detailed list of keyboard country codes, see Keyboard on page 44.
No backlight L01072-xxx
Backlit L01071-xxx
(3) Power button board L01044-001
(4) Top cover L01089-001
(5) TouchPad L01056-001
(6) Speaker assembly L01087-001
(7) Fingerprint reader assembly (includes cable) L01091-001
(8) Card reader board L01045-001
(9) Battery, Li-ion (4-cell, 48 WHr, 4.21 Ah) 851610-855
(10) USB board L01043-001
(11) Fan L01088-001
(12) RTC battery 746439-001
(13) System board (includes replacement thermal material)
All system boards use the following part numbers:
xxxxxx-001: Non-Windows operating system
xxxxxx-601: Windows 10 operating system
Models with UMA graphics:
●
Intel Core i7-8550U processor L01042-xxx
●
Intel Core i5-8350U processor L01041-xxx
●
Intel Core i5-8250U processor (WWAN models) L01040-xxx
●
Intel Core i5-8250U processor L01039-xxx
●
Intel Core i5-7200U processor L06797-xxx
●
Intel Core i3-7100U processor (WWAN models) L01038-xxx
●
Intel Core i3-7100U processor L01037-xxx
●
Intel Core i3-6006U processor L01036-xxx
●
Intel Celeron 3865U processor L01035-xxx
Models with 2 GB of discrete graphics:
●
Intel Core i7-8550U processor L01081-xxx
●
Intel Core i5-8350U processor L01080-xxx
Computer major components 19
