Speaker assembly
Description Spare part number
Speaker assembly L01087-001
Before removing the speaker assembly, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Place the computer in “Battery Safe mode” (Battery Safe mode on page 32).
3. Disconnect all external devices connected to the computer.
4. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet, and
then unplugging the AC adapter from the computer.
5. Remove the following components:
a. Service doors (Service doors on page 33).
b. Hard drive (Hard drive on page 41)
c. Keyboard (Keyboard on page 44)
d. Top cover (Top cover on page 48)
Remove the speaker assembly:
1. Position the top cover upside-down.
2. Remove the 2 Phillips M2.0×6.0 screws (1) that secure the speaker assembly to the top cover.
3. Remove the cable from the clips in the top cover (2).
Component replacement procedures 55
