Where used: 8 screws that secure the display bezel to the display enclosure
Where used: 21 screws that secure the top cover to the base enclosure on computers with 14-in
displays
Phillips PM2.5×11.0 captive screw
Color Quantity Length Thread Head diameter
Black 1 11.0 mm 2.5 mm 5.0 mm
Where used: One captive screw (secured by a C-clip) that secures the hard drive to the computer
144 Chapter 7 Screw listing
