Planning and Implementation for the 5400zl/8200zl Switches
Planning Your PoE Configuration
Planning and
Implementation for the
5400zl/8200zl Switches
Table 10-1. 5406zl/8206zl System Power Configurations
Table 10-2. 5406zl/8206zl System Power Configurations (J9306A)
Table 10-3 shows the maximum PoE power available for various power
configurations.
Table 10-3. 5406zl/8206zl Power Configurations for PoE Only (not PoE+)
Number of Power Supplies Redundancy Model
J8712A
(110 or 220 V)
J8713A
(220 V only)
N + 1 or Full Redundant System Power
System Power(12v) 10- None
2 0 Full up to 600 W system power
01- None
0 2 Full Up to 600 W system power
Number of Power Supplies Redundancy Model
J9306A N + 1
or
Full
Redundant System Power
System Power (12v) @ 110-127 V @ 200-240 V
10- None
2 0 Full up to 600 W system power
01 - None
0 2 Full Up to 600 W system power
Switch Model 5406zl/
8206zl
Number of Power Supplies Redundancy Model Non-Redundant
Power Available
J8712A
(110 or 220 volts)
J8713A
(220 volts only)
N + 1
or
Full
Redundant PoE Power Non-Redundant
PoE Power
PoE Power (50v)
Internal
10-None 273 W
2 0 Full Up to 273 W 546 W
01-None 900 W
0 2 Full Up to 900 W 1800 W
