Removing bezel blanks
On some models, there are bezel blanks covering one or more drive bays that need to be removed
before installing a drive. To remove a bezel blank:
1. Remove the access panel and front bezel.
2. Remove the bezel blank for the appropriate drive:
To remove a 5.25-inch bezel blank, press inward on the retaining tabs that hold the bezel
blank in place (1) then pull the bezel blank from the front bezel (2).
NOTE: After removing the 5.25-inch drive bezel blank and installing a drive, you can
install an optional bezel trim piece (available from HP) that surrounds the front of the drive.
To remove a 3.5-inch bezel blank, press outward on the two retaining tabs that hold the
bezel blank in place (1) and rotate the bezel blank back and to the right to remove it (2).
ENWW Removing bezel blanks 15
