18. Lock any security devices that were disengaged when the access panel was removed.
19. Reconfigure the computer, if necessary.
Drive positions
1 Slim optical drive bay
2 3.5-inch internal hard drive bay
3 3.5-inch drive bay for optional drives (media card reader shown)
4 2.5-inch internal hard drive bay
NOTE: The drive configuration on your computer may be different than the drive
configuration shown above.
To verify the type and size of the storage devices installed in the computer, run Computer Setup.
68 Chapter 3 Small Form Factor (SFF) hardware upgrades ENWW
