8. Before installing an expansion card, remove the expansion slot cover or the existing expansion
card.
NOTE: Before removing an installed expansion card, disconnect any cables that may be
attached to the expansion card.
a. If you are installing an expansion card in a vacant socket, remove the appropriate
expansion slot cover on the back of the chassis. Lift the expansion slot cover from the
expansion slot.
b. If you are removing a PCI Express x1 card, hold the card at each end and carefully rock it
back and forth until the connectors pull free from the socket. Lift the card straight up to
remove it. Be sure not to scrape the card against other components.
22 Chapter 2 Tower (TWR) hardware upgrades ENWW
