8. Slide the drive into the drive bay, making sure to align the guide screws with the guide slots, until
the drive snaps into place.
9. If installing a USB 3.0 media card reader, you must use the USB 3.0 to USB 2.0 adapter and
connect the adapter cable from the media card reader to the USB 2.0 connector on the system
board labeled MEDIA.
NOTE: Refer to System board connections on page 60 for an illustration of the system board
drive connectors.
10. Replace the front bezel.
11. Replace the computer access panel.
12. Reconnect the power cord and any external devices, then turn on the computer.
13. Lock any security devices that were disengaged when the access panel was removed.
ENWW Installing and removing drives 35
