11. If installing a USB 3.0 media card reader, you must use the USB 3.0 to USB 2.0 adapter and
connect the adapter cable from the media card reader to the USB 2.0 connector on the system
board labeled MEDIA.
NOTE: Refer to System board connections on page 60 for an illustration of the system board
drive connectors.
12. Rotate the drive cage back down to its normal position.
CAUTION: Be careful not to pinch any cables or wires when rotating the drive cage down.
13. Replace the front bezel.
14. Replace the computer access panel.
15. If the computer was on a stand, replace the stand.
ENWW Installing and removing drives 75
