HP ProDesk 600 G1 Small Form Factor Hardware Reference Guide

10. Connect the power cable (1) and data cable (2) to the back of the hard drive.
NOTE: If the 2.5-inch hard drive is the primary drive, connect the data cable to the dark blue
SATA connector labeled SATA0 on the system board. If it is a secondary drive, connect the data
cable to one of the light blue SATA connectors on the system board.
11. Rotate the drive cage back down to its normal position.
CAUTION: Be careful not to pinch any cables or wires when rotating the drive cage down.
12. Replace the computer access panel.
13. If the computer was on a stand, replace the stand.
14. Reconnect the power cord and any external devices, then turn on the computer.
15. Lock any security devices that were disengaged when the access panel was removed.
86 Chapter 3 Small Form Factor (SFF) hardware upgrades ENWW

HP ProDesk 600 G1 Small Form Factor Specifications

General

Brand	HP
Model	ProDesk 600 G1 Small Form Factor
Category	Desktop
Language	English
