HP PROLIANT DL160 G5 User Manual

2. On the left side of the window, select Add/Remove Windows Components. The Windows
Components Wizard appears.
3. Select Other Network File and Print Services and click the Details button. The Other Network File
and Print Services window is displayed.
4. Uncheck the Microsoft Services for NFS subcomponent.
5. Click OK, then Next, followed by Finish.
NOTE:
Uninstalling Microsoft Services for NFS removes two primary services:
• Server for NFS
• User Name Mapping
After setting up clustering, should you choose to reinstall Microsoft NFS, follow these steps:
1. Select Start > Settings > Control Panel > Add or Remove Programs. The Add or Remove Programs
window is displayed.
2. On the left side of the window, select Add/Remove Windows Components. The Windows
Components Wizard appears.
3. Select Other Network File and Print Services and click the Details button. The Other Network File
and Print Services window is displayed.
4. Check the Microsoft Services for NFS subcomponent.
5. Click OK, then Next, followed by Finish.
6. After NFS is installed, you can view the details of the Microsoft Services for NFS subcomponent
to see which of its subcomponents were installed. The subcomponents listed below are preinstalled
at the factory. Verify that the Server for NFS and User Name Mapping services have been
reinstalled.
• Microsoft Services for NFS Administration
• RPC External Data Representation
• RPC Port Mapper
• Server for NFS
• Server for NFS Authentication
• User Name Mapping
Checklists for cluster server installation
These checklists assist in preparing for installation. Step-by-step instructions begin after the checklists.
Network requirements
• A unique NetBIOS cluster name
• For each node deployed in the cluster the following static IP addresses are required:
• One for the network adapters on the private network
• One for the network adapters on the public network
• One for the virtual server itself
A single static cluster IP address is required for the entire cluster.
HP ProLiant Storage Server 135

HP PROLIANT DL160 G5 Specifications

General

Chipset	Intel 5000P
Hard Drives	SAS or SATA
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Form Factor	1U Rack
Processor	Intel Xeon 5400 series
Memory	Up to 32GB
Drive Bays	Four (4) 3.5-inch LFF SAS/SATA hot-plug drive bays or Eight (8) 2.5-inch SFF SAS/SATA hot-plug drive bays
RAID Support	HP Smart Array E200
Network Interface	Embedded NC373i Multifunction Gigabit Network Adapter
Expansion Slots	1 PCIe x8
