StatusDescriptionItem
N/AMouse connector10
N/AKeyboard connector11
N/AVideo connector12
Blue = Activated
Flashing blue = Server remotely managed
Off = Deactivated
Rear UID button and LED13
Both off = No AC power to any power supply
Fail LED flashing amber, Power LED off = Power supply failure (over
current)
Fail LED amber, Power LED off = No AC power to this power supply
Fail LED off, Power LED flashing green = AC power present, standby
mode
Fail LED = off, Power LED green = Normal
Fail LED (amber)14
Power LED (green)15
Green or flashing green = Network activity
Off = No network activity
Activity LED16
Green = Linked to network
Off = Not linked to network
Link LED17
SAS and SATA hard drive LEDs
The following figure shows SAS/SATA hard drive LEDs. These LEDs are located on all HP ProLiant
hot plug hard drives.
Server components48

HP PROLIANT DL160 G5 Specifications

General

Chipset	Intel 5000P
Hard Drives	SAS or SATA
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Form Factor	1U Rack
Processor	Intel Xeon 5400 series
Memory	Up to 32GB
Drive Bays	Four (4) 3.5-inch LFF SAS/SATA hot-plug drive bays or Eight (8) 2.5-inch SFF SAS/SATA hot-plug drive bays
RAID Support	HP Smart Array E200
Network Interface	Embedded NC373i Multifunction Gigabit Network Adapter
Expansion Slots	1 PCIe x8
