Connectors, Switches, and Status Indicators
5-6 Compaq ProLiant DL360 Server Maintenance and Service Guide
COMPAQ CONFIDENTIAL Codename: MicroMachines Part Number: 169616-006 Last Saved On: 1/7/02 10:57 AM
System Identification Switch (SW1)
Switch settings are preconfigured for shipping. All settings are reserved. Do not change these
settings.
CAUTION: Do not change switch settings because incorrectly set switches may result in
damage to the server.
System Configuration Switch (SW2)
The following table defines the function for each switch setting on SW2, a six-position
maintenance switch.
Table 5-4: System Configuration Switch (SW2) Settings
Switch Description Default Position
1 Video disable override Off
2 Lock configuration Off
3 Rack mount On
4 Diskette drive boot override Off
5 Password disable Off
6 Maintenance Off
