Cable Routing Diagrams
3-2 Compaq ProLiant DL360 Maintenance and Service Guide
COMPAQ CONFIDENTIAL Codename: MicroMachines Part Number: 169616-006 Last Saved On: 12/20/01 3:56 PM
Optional Smart Array/SCSI Controller Cabling
The following figures identify the proper routing of the optional Smart Array/SCSI controller
interface assembly cable leading from the system board to the optional Smart Array/SCSI
controller installed in the 64-bit expansion slot.
Figure 3-2: Smart Array/SCSI controller interface assembly installed
(PCI riser board assembly removed for clarity)
Figure 3-3: Smart Array/SCSI controller interface assembly cable
connection to expansion board
