Diagnostics and Troubleshooting
Compaq ProLiant DL360 Server Maintenance and Service Guide 4-29
COMPAQ CONFIDENTIAL Codename: MIcroMachines Part Number: 169616-006 Last Saved On: 12/21/01 9:05 AM
100 – 199, Primary Processor Test Error Codes
The 100 series of diagnostic error codes identifies failures with processor and system board
functions.
Table 4-3: Primary Processor Test Error Codes
Error Code Description Recommended Action
101-xx CPU test failed. Replace the processor board
and retest.
103-xx DMA page registers test failed. Replace the processor board
and retest.
104-xx Interrupt controller master test
failed.
105-xx Port 61error.
106-xx Keyboard controller self-test
failed.
107-xx CMOS RAM test failed. 1. Replace the battery/clock
module and retest.
2. Replace the system board
and retest.
108-xx CMOS interrupt test failed.
109-xx CMOS clock load data test
failed.
110-xx Programmable timer load data
test failed.
Replace the processor board
and retest.
111-xx Refresh detect test failed.
112-xx Speed test slow mode out of
range
113-xx Protected mode test failed.
114-xx Speaker test failed. 1. Verify the speaker
connection and retest.
2. Replace the speaker and
retest.
3. Replace the system board
and retest.
116-xx Cache test failed. Replace the system board and
retest.
continued
