HP ProLiant DL360e Gen8 - System Components

Illustrated parts catalog 19
System components
Item Description
Spare part
number
Customer self
repair (on page
6
)
8
System board assemblies (include alcohol pad and thermal
compound)
— —
System board assembly for Intel Xeon E5-2400 processors 684956-001 Optional
2
a) System board with subpan — —
b) System board tray* — —
c) System board cables* — —
d) System board handle* — —
e) Processor baffle, right* — —
f) Processor baffle, left* — —
g) Processor baffle, middle* — —
h) Power supply baffle* — —
System board assembly for Intel Xeon E5-2400 and E5-2400
v2 processors
732151-001 Optional
2
a) System board with subpan* — —
b) System board tray* — —
c) System board cables* — —
d) System board handle* — —
e) Processor baffle, right* — —
