Illustrated parts catalog 21
Item Description
Spare part
number
Customer self
repair (on page
)
a) 2 GB, single-rank, x8, PC3-12800E-11 684033-001 Mandatory
1
b) 2 GB, single-rank x8 PC3L-10600E-9* 664694-001 Mandatory
1
c) 2 GB, single-rank x8 PC3L-12800E-11* 715279-001 Mandatory
1
d) 4 GB, single-rank x4 PC3-12800R-11* 664689-001 Mandatory
1
e) 4 GB, single-rank x4 PC3L-10600R-9* 664688-001 Mandatory
1
f) 4 GB, single-rank, x4 PC3L-12800R-11* 715282-001 Mandatory
1
g) 4 GB, dual-rank x8 PC3-12800E-11* 684034-001 Mandatory
1
h) 4 GB, dual-rank x8 PC3L-10600E-9* 664695-001 Mandatory
1
i) 4 GB, dual-rank, x8 PC3L-12800E-11* 715280-001 Mandatory
1
j) 8 GB, single-rank x4 PC3-12800R-11* 664691-001 Mandatory
1
k) 8 GB, single-rank, x4 PC3L-12800R-11* 735302-001 Mandatory
1
l) 8 GB, dual-rank x4 PC3-12800R-11* 698807-001 Mandatory
1
m) 8 GB, dual-rank x4 PC3L-10600R-9* 664690-001 Mandatory
1
n) 8 GB, dual-rank, x4 PC3L-12800R-11* 715283-001 Mandatory
1
o) 8 GB, dual-rank x8 PC3-12800E-11* 684035-001 Mandatory
1
p) 8 GB, dual-rank x8 PC3L-10600E-9* 664696-001 Mandatory
1
q) 8 GB, dual-rank, x8, PC3L-12800E-11* 715281-001 Mandatory
1
r) 16 GB, dual-rank x4 PC3-12800R-11* 684031-001 Mandatory
1
s) 16 GB, dual-rank x4 PC3L-10600R-9* 664692-001 Mandatory
1
t) 16 GB, dual-rank, x4 PC3L-12800R-11* 715284-001 Mandatory
1
u) 32 GB, quad-rank x4 PC3L-10600L-9* 664693-001 Mandatory
1
13
Hot-plug fan module 667882-001 Mandatory
1
14
LFF drives (8.89 cm, 3.5 in), hot-plug — —
SAS — —
a) 450-GB ENT hard drive 653951-001 Mandatory
1
b) 600-GB ENT hard drive* 653952-001 Mandatory
1
c) 1-TB MDL hard drive* 653947-001 Mandatory
1
d) 2-TB MDL hard drive* 653948-001 Mandatory
1
e) 3-MDL TB hard drive* 653959-001 Mandatory
1
SATA — —
a) 80-GB EV solid state drive* 734563-001 Mandatory
1
b) 100-GB MLC EM solid state drive* 653968-001 Mandatory
1
c) 120-GB EV solid state drive* 718300-001 Mandatory
1
d) 200-GB MLC EM solid state drive* 653969-001 Mandatory
1
e) 240-GB EV solid state drive* 741239-001 Mandatory
1
