10 HP ProLiant DL380 Generation 3 Server Maintenance and Service Guide
Item Description Assembly
Part Number
Spare Part
Number
a) Power button/LED board cable, 14 pin 219048-001 —
b) PCI Hot Plug LED board cable 219049-002 —
c) Universal Media Bay cable, 50 pin 314014-006 —
26 Miscellaneous cable kit * — 289569-001
a) Diskette drive cable 235183-001 —
b) Smart Array 5i Plus memory module interface cable 262695-006 —
Rack Mounting Hardware
27 Rack mounting hardware kit * — 289570-001
Miscellaneous
28 Hardware kit * — 228527-001
a) Screws, T-15, flathead 228213-001 —
b) Expansion slot cover 228072-001 —
c) Screws, 6-32 192308-009 —
29 Plastics kit * — 289555-001
a) PCI slot release lever 228194-001 —
b) PCI lightpipe, rear 279061-001 —
c) PCI lightpipe, cover 218518-001 —
d) PCI riser cage door latch 279062-001 —
e) Thumbscrew with molded cap, PCI slot 1 179333-003 —
f) Battery-Backed Write Cache Enabler bracket 266643-001 —
30 AC power cord * 163719-002 187335-001
31 DC power cord with pigtail * 262608-001 316051-001
32 CD ejector assembly * 233905-001 237158-001
33 PCI expansion board ejector/divider * 279035-001 289547-001
34 Battery, 3.3 V, lithium * 334149-001 179322-001
35 Country kit * 284756-001 289566-001
HP CONFIDENTIAL
File Name: 291916-6.doc Last Saved On: 2/5/04 2:26 PM
