Illustrated Parts Catalog 9
Item Description Assembly
Part Number
Spare Part
Number
e) Intel® 3.06-GHz Xeon 1-MB L3 cache 336417-001 336856-001
f) Intel® 3.20-GHz Xeon 1-MB L3 cache 336417-002 347406-001
g) Intel® 3.20-GHz Xeon 2-MB L3 cache 354750-001 356534-001
Boards
13 PPM, 12 V, 81 A 292718-001 289564-001
14 Smart Array 5i Plus memory module 011665-001 260741-001
15 System board, with processor cages and system battery
a) 2.4-GHz and 2.8-GHz 512-KB cache models (primary spare) 011656-001 289554-001
b) 2.8-GHz 1-MB cache and 3.06-GHz and above models 011986-002 314670-001
16 Power converter module
a) 2.4-GHz and 2.8-GHz 512-KB cache models 266240-001 289560-001
b)2.8-GHz 1-MB cache and 3.06-GHz and above models 309629-001 316052-001
17 SCSI backplane, 6 bay 011659-001 289552-001
18 Universal Media Bay adapter board 010984-001 228504-001
19 SCSI terminator 011730-001 289563-001
20 Power button/LED board 010963-001 228503-001
Media Devices
21 Diskette drive, slimline, 1.44 MB 279983-001 289550-001
22 CD-ROM drive, removable slimline, IDE, 24X 222837-001 228508-001
23 DVD-ROM drive, removable slimline, 8X * 264007-B21 268795-001
Cables
24 SCSI cable kit *
289567-001
a) SCSI cable, short, 68 pin 199606-019 —
b) SCSI cable, long, 68 pin 166298-038 —
c) System cable, SCSI, 50 pin 279161-001 —
25 Signal cable kit * — 228518-001
HP CONFIDENTIAL
File Name: 291916-6.doc Last Saved On: 2/5/04 2:26 PM
