Removal and Replacement Procedures 61
To replace the component, reverse the removal procedure.
For more information about battery replacement or proper disposal, contact your
authorized reseller or your authorized service provider.
System Board
To remove the component:
1. Power down the server.
2. Extend or remove the server from the rack ("Extending the Server from the
Rack" on page 16
, "Removing the Server from the Rack" on page 18).
3. Remove the access panel ("Removing the Access Panel" on page 19
).
4. Remove the PCI riser cage ("PCI Riser Cage" on page 44
).
CAUTION: To prevent damage to the server or expansion
boards, power down the server and remove all AC power cords before
removing or installing the PCI riser cage.
5. Remove the front fan bracket ("Front Fan Bracket" on page 40).
IMPORTANT: For this procedure, you do not need to remove the hot-
plug fans from the front fan bracket. When reinstalling the front fan
bracket, press the top of each fan to be sure it seats securely.
6. Remove the hot-plug fans from the rear fan bracket.
7. Remove any DDR SDRAM DIMMs ("DIMMs" on page 54
).
8. Remove the processors ("Processor" on page 55
).
9. Remove the PPMs ("PPM" on page 57).
10. Remove the Smart Array 5i Plus memory module ("Smart Array 5i Plus
Memory Module" on page 58
).
11. Disconnect all cables connected to the system board.
