Server Component Identification 91
Item LED Description Status
8 DIMM 3B failure Amber = Memory failed
Off = Normal
9 DIMM 2A failure Amber = Memory failed
Off = Normal
10 DIMM 1A failure Amber = Memory failed
Off = Normal
11 PPM 1 failure Amber = PPM failed
Off = Normal
12 iLO diagnostic LEDs Refer to the HP Integrated Lights-Out User
Guide on the Documentation CD.
13 Processor 1 failure Amber = Processor failed
Off = Normal
14 Processor 2 failure Amber = Processor failed
Off = Normal
System LEDs and Internal Health LED Combinations
When the internal health LED on the front panel illuminates either amber or red,
the server is experiencing a health event. Combinations of illuminated system
LEDs and the internal health LED indicate system status.
The front panel health LEDs indicate only the current hardware status. In some
situations, Insight Manager 7 may report server status differently than the health
LEDs because the software tracks more system attributes.
