Expansion Slots
Primary Riser
(Standard)
Expansion
Slots #
Technology
Bus
Width
**
Connector
Width
Bus Number
*
Form Factor
Notes
1
PCIe 3.0
X16 X16
7
Full Length,
Full Height
Slot
Proc 1
2
PCIe 3.0
X8 X8
10
Half Length,
Full Height
Slot
Proc 1
3
PCIe 2.0
X4 X8
13
Half Length,
Full Height
Slot
Chipset
* Default bus assignment (in decimal). Inserting cards with PCI bridges may alter the actual bus assignment
number
** Indicates the number of physical electrical lanes running to the connector.
NOTE:
When populating the second optional riser slot, the second processor must be installed.
NOTE:
All slots support up to 150w PCIe cards, but an additional Power Cord Option is required (PN
669777-B21). See Option Section below for offering.
PCIe Riser
(Optional 3-slot)
Expansion
Slots #
Technology
Bus
Width
**
Connector
Width
Bus Number
*
Form Factor
Notes
4
PCIe 3.0
X16 X16
16
Full length,
full height slot
Proc 2
5
PCIe 3.0
X8 X8
20
Half length,
full height slot
Proc 2
6
PCIe 3.0
X8 X8
23
Half length,
full height slot
Proc 2
* Default bus assignment (in decimal). Inserting cards with PCI bridges may alter the actual bus assignment
number
** Indicates the number of physical electrical lanes running to the connector.
NOTE:
When populating the second optional riser slot, the second processor must be installed.
NOTE:
All slots support up to 150w PCIe cards, but an additional Power Cord Option is required (669777-
B21). See Option Section below for offering
PCIe Riser
(Optional 2-slot)
Expansion
Slots #
Technology
Bus
Width
**
Connector
Width
Bus Number
*
Form Factor
Notes
4
PCIe 3.0
X16 X16
16
Full length,
Full height
slot
Proc 2
5
PCIe 3.0
X16 X16
16
Half Length,
Full Height
Proc 2
* Default bus assignment (in decimal). Inserting cards with PCI bridges may alter the actual bus assignment
number
** Indicates the number of physical electrical lanes running to the connector.
QuickSpecs
HP ProLiant DL380p Generation8 (Gen8)
Standard Features
DA - 14212 North America — Version 38 — July 22, 2013
Page 5
