Item Description Assembly
part number
Spare part
number
Customer
self repair
(on page 5)
System components
12 Hot-plug fan 463172-001 496066-001 Mandatory
1
13 Hot-plug power supply, 1200-W 490594-001 498152-001 Mandatory
1
14 PCI riser cage, with non-hot-plug PCIe riser 463170-001 496060-001 Optional
2
15 Optical drive cage 463175-001 496076-001 Mandatory
1
16 Hard drive cage — — —
a) SFF hard drive cage 463173-001 496074-001 Mandatory
1
b) LFF hard drive cage* 463174-001 496075-001 Mandatory
1
17 Processor — — —
a) 2.3-GHz, AMD Opteron™ Model 2376* ** 495643-003 502922-001 Optional
2
b) 2.4-GHz, AMD Opteron™ Model 2378* ** 495643-002 500514-001 Optional
2
c) 2.5-GHz, AMD Opteron™ Model 2380* ** 495643-001 500515-001 Optional
2
d) 2.6-GHz, AMD Opteron™ Model 2382* ** 496543-004 505635-001 Optional
2
e) 2.7-GHz, AMD Opteron™ Model 2384* ** 495643-005 505917-001 Optional
2
f) 2.9-GHz, AMD Opteron™ Model 2389 HE*
**
530535-003 535801-001 Optional
2
g) 2.8-GHz, AMD Opteron™ Model 2387 HE*
**
530535-002 534250-001 Optional
2
h) 2.5-GHz, AMD Opteron™ Model 2381 HE*
**
530534-002 538607-001 Optional
2
18 Processor heatsink, thermal grease, and alcohol
pad
469886-001 496064-001 Optional
2
Boards
19 System board assembly 488896-001 507686-001 Optional
2
20 Power supply backplane 462954-001 496062-001 Optional
2
21 Hard drive backplane — — —
a) SAS backplane 451283-001 507690-001 Optional
2
b) 6-bay hard drive backplane* 457174-001 496079-001 Optional
2
22 Systems Insight Display 451281-001 496073-001 Mandatory
1
23 Controller board with heatsink 013159-005 507694-001 Mandatory
1
24 PCI riser boards
a) PCI-X* 451279-001 496077-001 Mandatory
1
b) PCIe* 451280-001 496078-001 Mandatory
1
c) PCI* 488898-001 507691-001 Mandatory
1
Memory
25 DIMMs — — —
Illustrated parts catalog 20
